API Documentation for PowerSoftMD Certified Version MU3B

The PowerSoftMD Certified EHR, hereafter referred to as PowerSoftMD or PowerSoftMD EHR, API documentation provides information for searching and fetching patient data from the Common Clinical Data Set as defined by the Meaningful Use 2015 “Stage 3” regulations. The search criteria are intended to meet the 2015 Edition ONC Certification criterion Patient Selection 170.315(g)(7), Category Search 170.315(g)(8) and All Category Search 170.315(g)(9). Access is based on the HL7 FHIR Data Access Framework (DAF) profile and draws requirements from DSTU3. Generally, only required DSTU3 data elements are provided.


PowerSoftMD uses the restful based service architecture which allows seamless integration over the HTTPS protocol. This means that clients that can communicate over HTTPS can easily communicate with the API service. Data passed to the server is supported and provided in XML.

Registration for API access must be conducted with PowerSoftMD clients.

PowerSoftMD clients may suspend or revoke an API identifier at its discretion at any time as a result of a non-conformance. If this happens, you will not be able to communicate with PowerSoftMD's clients until the non-conformance is resolved. You may contact PowerSoftMD client office on resolving the problem that led to the client identifier being suspended.

Direct access to PowerSoftMD is not required to develop or test your products. Testing can be done via a sandbox FHIR server. Your access to PowerSoftMD documentation does not give you permission to access PowerSoftMD, and does not give you permission to access PowerSoftMD Clients. Your access to PowerSoftMD is only granted by PowerSoftMD Clients. You must follow the PowerSoftMD FHIR Guidelines, including compliance to the ONC Certification Criteria.

PowerSoftMD uses a simple information identification scheme to make finding information related to a specific patient easier.

Terms of Use

Your use of this site, including, without limitation, accessing the PowerSoftMD APIs, is subject to these PowerSoftMD API Terms of Use. PowerSoftMD may update and modify the PowerSoftMD API Terms of Use at its sole discretion and without notice. API Developers and other users of this site should regularly check this site for updates to the PowerSoftMD API Terms of Use. Further, PowerSoftMD clients may deploy and integrate the API in ways where the client would be able to layer on its own specific terms of use unique to that organization.

Ownership

PowerSoftMD retains all ownership of PowerSoftMD property and reserves all of its applicable rights with respect to the content of this site, PowerSoftMD EHR and PowerSoftMD APIs. Nothing in the PowerSoftMD API Terms of Use or any documentation associated with the PowerSoftMD APIs is intended to convey any transfer of ownership of PowerSoftMD's property.

Source Code or Software

PowerSoftMD API Developers may test applications by using a FHIR Server Sandbox or by collaborating with the PowerSoftMD Client office; it is not necessary to access the PowerSoftMD EHR to test applications. In connection with providing the PowerSoftMD APIs, PowerSoftMD does not offer a license to use the PowerSoftMD EHR, or access to the PowerSoftMD EHR to any party that has not purchased a license to the PowerSoftMD EHR. PowerSoftMD will not make any PowerSoftMD source code available to any party in connection with the PowerSoftMD APIs.

Indemnity

By accessing the PowerSoftMD APIs, you assume the risk of liability for, and agree to indemnify and hold harmless PowerSoftMD and its affiliates, employees, clients, partners, dealers (collectively, "PowerSoftMD") and will defend PowerSoftMD from and against any and all liabilities, losses, claims, damages, claims and expenses (including legal expenses of any kind and nature) arising out of, or relating to, directly or indirectly: (a) any action or omission related to (i) your use of the PowerSoftMD APIs or (ii) the development, content, or performance of third party applications developed by you or (b) your failure to comply with any federal, state or local laws, rules or regulations in connection with your use of the PowerSoftMD APIs.

Warranty Disclaimers

PowerSoftMD APIs are provided on an "as-is" basis with all faults and defects, and without any warranty whatsoever. The entire risk as to the quality and performance of the PowerSoftMD APIs is with the third-party Developer. PowerSoftMD shall be responsible for the performance of PowerSoftMD developed applications. PowerSoftMD does not provide any service level agreements or performance objectives for availability, response time or any other performance measurement associated with the PowerSoftMD APIs.

For any issues alleged to be caused solely by the PowerSoftMD APIs, API Users may report issues to PowerSoftMD at support@PowerSoftMD.com. PowerSoftMD will make reasonable efforts to investigate and correct such issues at its sole discretion towards the functioning of the PowerSoftMD API as intended.

Introduction

Fast Healthcare Interoperability Resources, or FHIR, is a standard way of defining an API for healthcare resources. More information can be found at the https://www.hl7.org/FHIR/.



The PowerSoftMD FHIR API is based on DSTU 3 of the FHIR standard. The PowerSoftMD FHIR API is a RESTful implementation for an API. FHIR is resource-based. The resources are healthcare or related resources, such as patient, problems, immunizations or medications.



These resources are accessed through HTTP to retrieve a resource with a GET. To update a resource a POST is performed.



The PowerSoftMD FHIR API supports XML, the Client’s FHIR server may support JSON as well as XML.



Authorization and Registration for Patient Access

Security, Registration, and Authentication may be dependent on the FHIR Server setup selected by Client offices and the way they configure it. Check with the client office. The username and password provided by the client office are passed as “BASIC” authentication headers on all requests through the TLS encrypted connection to the clients https web address.



This means the username and password are concatenated with a colon, base 64 encoded, and prefixed with “Basic ” (without the quotes,) i.e. “Basic dXNlcm5hbWU6cGFzc3dvcmQ=”

This string is sent as the Authorization header.



Exception Handling

Exceptions will return an OperationOutcome segment instead of the expected resource, or for Authorization errors, a completely non XML http error with an eplanation of what was wrong with the request.



For example, xml response for non-existent resources is similar to the following:

<OperationOutcome xmlns="http://hl7.org/fhir">

   <issue>

      <severity value="error"/>

      <code value="processing"/>

      <diagnostics value="Resource Patient/FJF0000212311902A is not known"/>

   </issue>

</OperationOutcome>



Retrieving information

To retrieve demographic information for the patient with ID 1501, issue the following GET request:

 GET https://your.FHIRserver.com/Patient/1501A

API Endpoints and Syntax

API Name

API Endpoint URL

Patient Search

GET https://your.FHIRserver.com/Patient?criteria

     Search Criteria

    family=lastname    given=firstname    birthdate=yyyy-mm-dd

     Search Criteria

    gender=f/m    telecom=nnnnnnnnnn   address=anypartofaddress

     Search Criteria

    Note: Multiple criteria can be used with & between criteria

     Search Criteria

    Example: family=flintstone&given=fred&birthdate=1974-05-15

Patient

GET https://your.FHIRserver.com/Patient/patientidA

Problem

GET https://your.FHIRserver.com/Condition/patientidBincrement

Medication

GET https://your.FHIRserver.com/Medication/patientidCincrement

Allergy

GET https://your.FHIRserver.com/AllergyIntolerance/patientidDincrement

LabTests

GET https://your.FHIRserver.com/TestScript/patientidKincrement

LabResults

GET https://your.FHIRserver.com/DiagnosticReport/patientidHincrement

Vital Signs



     Body Temperature

GET https://your.FHIRserver.com/Observation/patientidEincrement-1

     Systolic Blood Pressure

GET https://your.FHIRserver.com/Observation/patientidEincrement-2

     Diastolic Blood Pressure

GET https://your.FHIRserver.com/Observation/patientidEincrement-3

     Body Weight

GET https://your.FHIRserver.com/Observation/patientidEincrement-4

     Body Height

GET https://your.FHIRserver.com/Observation/patientidEincrement-5

     Heart Rate

GET https://your.FHIRserver.com/Observation/patientidEincrement-6

     Respiratory rate

GET https://your.FHIRserver.com/Observation/patientidEincrement-7

     Glucose in Serum/Plasma

GET https://your.FHIRserver.com/Observation/patientidEincrement-8

     Last menstrual period

GET https://your.FHIRserver.com/Observation/patientidEincrement-A

     Oxygen saturation

GET https://your.FHIRserver.com/Observation/patientidEincrement-B

     Inhaled oxygen concentration

GET https://your.FHIRserver.com/Observation/patientidEincrement-C

     Head Occipital circumference

GET https://your.FHIRserver.com/Observation/patientidEincrement-D

     Body mass index (BMI)

GET https://your.FHIRserver.com/Observation/patientidEincrement-E

Procedure

GET https://your.FHIRserver.com/Procedure/patientidFincrement

Care Team

GET https://your.FHIRserver.com/Practitioner/patientidNincrement

Immunization

GET https://your.FHIRserver.com/Immunization/patientidGincrement

Implantable Devices

GET https://your.FHIRserver.com/Device/patientidIincrement

Implantable Device Installation

GET https://your.FHIRserver.com/ActivityDefinition/patientidIincrement-A

Assessment and Plan

GET https://your.FHIRserver.com/CarePlan/patientidLincrement

Goals

GET https://your.FHIRserver.com/Goal/patientidJincrement

Health Concerns

GET https://your.FHIRserver.com/Condition/patientidMincrement

CCDA ID List (Returns ccda ids)

GET https://your.FHIRserver.com/List/patientidQ

CCDA

GET https://your.FHIRserver.com/Binary/ccdaid



PowerSoftMD Architecture



Searching for a patient

Examples:

GET https://your.FHIRserver.com/Patient?name=Jane

GET https://your.FHIRserver.com/Patient?given=Jane&gender=female



The parameters available in the search query are dependent on the FHIR Server used. The following parameters are all available with Hapi FHIR Server:

Name

Description

_id

ID of the patient.

family

Portion of the last name of the patient.

given

Portion of the first or middle name of the patient.

gender

Patient's gender. For more information on this value set, see

https://www.hl7.org/FHIR/valueset-administrative-gender.html

birthdate

Patient's date of birth. For more information on this type, see https://www.hl7.org/FHIR/datatypes.html#date

telecom

Patient’s phone number.

address

Portion of the patient’s address.



Searching using a patient ID

A patient ID can be used to query for additional information. The search function is described above.

If the response returns one or more patients, the response contains the PID (or patient IDs) with a letter A as a suffix indicating a patient section.



<Bundle xmlns="http://hl7.org/FHIR">

   <type value="searchset"/>

   <total value="X"/>

   <entry>

      <resource>

         <Patient xmlns="http://hl7.org/FHIR">

            <id value="FJF0000212311901A"/>

            <language value="English"/>

            <text>

               <status value="generated"/>

            </text>

         </Patient>

      </resource>

      <search>

         <mode value="match"/>

      </search>

   </entry>

  [...]

</Bundle>



You can now use the PID in subsequent requests.

The PID can be used to find ALL data related to the patient.



Retrieving a patient

The patient's PID and suffix ‘A’ used to retrieve the patient is passed as part of the URL.



GET https://your.FHIRserver.com/Patient/patientidA



Name

Description

id

Patient's PID. This is retrieved using the search function.



A Patient record is returned on the query using the PID and suffix ‘A’. The following table describes the information returned.



Name

Description

identifier

Patient's PID. Patients are usually assigned a specific identifier that is unique within the system.

active

Is the patient's record active? The default value is true. Need to be able to mark a patient record as not to be used because it was created in error. If a record is inactive, and linked to an active record, then future patient/record updates should occur on the other patient.

name

Names associated with the patient. Can be multiple returned including prior.

telecom

Patient contact communication detail. This indicates the value in any kind of telecom details field for the patient.

gender

Patient's gender. Returns Male, Female, Other, or Unknown. Patient's gender. For more information on this value set, see

https://www.hl7.org/FHIR/valueset-administrative-gender.html

birthDate

Patient's date of birth.

address

Patient's postal address. Postal addresses are often used to record a location that can be visited to find a patient or person.

communication

Patient’s preferred language.

extension

Information not explicitly included in the FHIR standard. Includes Race, Ethnicity, and Smoking Status.



The xml response is similar to the following:

<Patient xmlns="http://hl7.org/FHIR">

   <id value="FJF0000212311901A"/>

   <language value="English"/>

   <extension url="2.16.840.1.113883.6.238">

      <valueExtension>

         <valueCode value="1002-5"/>

      </valueExtension>

   </extension>

   <extension url="2.16.840.1.113883.6.238">

      <valueExtension>

         <valueCode value="2054-5"/>

      </valueExtension>

   </extension>

   <extension url="2.16.840.1.113883.6.238">

      <valueExtension>

         <valueCode value="2135-2"/>

      </valueExtension>

   </extension>

   <extension url="2.16.840.1.113883.10.20.22.2.17">

      <valueExtension>

         <valueCode value="428061000124105"/>

      </valueExtension>

   </extension>

   <active value="true"/>

   <name>

      <use value="official"/>

      <text value="FRED J FLINTSTONE"/>

      <family value="FLINTSTONE"/>

      <given value="FRED"/>

      <given value="J"/>

   </name>

   <telecom>

      <system value="phone"/>

      <value value="314-555-1212"/>

      <use value="home"/>

      <rank value="1"/>

   </telecom>

   <gender value="male"/>

   <birthDate value="1901-12-31"/>

   <communication>

      <language>

         <coding>

            <system value="ISO 639-1"/>

            <code value="EN"/>

            <display value="English"/>

         </coding>

         <text value="English"/>

      </language>

   </communication>

</Patient>



Qualifying searches by date

Patient visits and CCDA records are stored as Lists. The patient's PID and suffix ‘Q’ is used to retrieve a List.



GET https://your.FHIRserver.com/List/patientidQ



Name

Description

id

Patient's PID. This is retrieved using the search function.



A List record is returned on the query using the PID and suffix ‘Q’. The following table describes the information returned.



Name

Description

id

List's ID. Lists are assigned a specific identifier that is based on the Patient’s ID.

identifier

Is Always “PSMD”

entry

An entry in the list of visits and CDA records. Contains Extensions and Items.

extension

Original File name for CDA document.

item-Reference

Absolute Path to the CDA document on the same server.

item-display

Date of the relevant visit in MMDDYYYY format.

subject

Patient this list is related to.

date

Date of visits a list links to. YYYY-MM-DD format.



Other resources have date values stored directly in the resource itself and can be directly searched for by patient and date. Dates are in a YYYY-MM-DD format.

Dates are passed as parameters on the URL. Comparators (>, <, <=, =>) are not supported and these are passed in as part of the date as shown below.

date=eq2018-01-01

date=gt2018-01-01

The following comparators are supported:



Comparator

Description

eq

equal

gt

greater than

ge

greater than or equal

lt

less than

le

less than or equal



Retrieving a patient's problems

The patient's PID used to retrieve the patient, a suffix ‘B’, and an incrementing number is passed as part of the URL to retrieve all problems.You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/Condition/patientidBincrement



GET https://your.FHIRserver.com/Condition?category=problem&onset-date=gedaterangelowerlimit&onset-date=ledaterangeupperlimit&subject=Patient/patientidA



Name

Description

id

The logical ID of the problem. This is based on the patient ID.

onset-date

The date the problem started.

subject

The patient that has the problem.

category

Always “problem” for patient problems.



The patient's problems or diagnosis are returned. The following table describes the information returned:



Name

Description

id

Condition record unique identifier.

clinicalStatus

Status of the problem. Valid entries include Active, Resolved

Code

ID of the condition, problem, or diagnosis. Select from SNOMED, ICD10, ICD9.

onsetString

Date the Problem started. YYYY-MM-DD format.

onsetDateTime

Date the Problem started. YYYY-MM-DD format.

subject

The patient that has the problem.



Retrieving a patient's Immunizations

The patient's PID used to retrieve the patient, a suffix ‘G’, and an incrementing number is passed as part of the URL to retrieve all immunizations. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/Immunization/patientidGincrement



GET https://your.FHIRserver.com/Immunization?date=gedaterangelowerlimit&date=ledaterangeupperlimit&patient=Patient/patientidA



Name

Description

id

The logical ID of the immunization. This is based on the patient ID.

date

The date the immunization occurred.

patient

The patient that had the immunization.



The patient's immunizations are returned. The following table describes the information returned.



Name

Description

id

Immunization record unique identifier.

status

Immunization current status. For more information on this value set, see medication-admin-status.

date

Date and time when the immunization was administered.

vaccineCode

Vaccine product administered. Values come from vaccine-code.

lotNumber

Vaccine lot number.

expirationDate

Vaccine expiration date.

site

Body site where the vaccine was administered.

route

How the vaccine entered the body.

doseQuantity

Amount of vaccine administered.

patient

The patient that had the immunization.



Retrieving Patient's Goals

The patient's PID used to retrieve the patient, a suffix ‘J’, and an incrementing number is passed as part of the URL to retrieve all goals. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/Goal/patientidJincrement



GET https://your.FHIRserver.com/Goal?start-date=gedaterangelowerlimit&start-date=ledaterangeupperlimit&subject=Patient/patientidA



Name

Description

id

The logical ID of the goal. This is based on the patient ID.

start-date

Date that the goal was set.

subject

Patient that the goal is for.



The patient's FHIR Goal is returned. The following table describes the information returned



Name

Description

id

Goal record unique identifier.

description

Desired outcome.

status

Indicates if the goal has been reached. Options include: Proposed, Planned, Accepted, Rejected, In-progress, Achieved, Sustaining, On-hold, and Cancelled.

statusDate

Date the status was last set.

startDateTime

Date that the goal was set.

subject

Patient that the goal is for.



Retrieving Patient's Implantable devices/UDI

The patient's PID used to retrieve the patient, a suffix ‘I’, and an incrementing number is passed as part of the URL to retrieve all devices. Fhir doesn’t support dates on the device itself, to search devices by date, see the next section about devices implantation events which link back to the device information.



GET https://your.FHIRserver.com/Device/patientidIincrement



Name

Description

id

The logical ID of the device. This is based on the patient ID.



The patient's implantable device is returned. The following table describes the information returned



Name

Description

id

Device record unique identifier.

identifier

Unique identifier assigned to a device. Note some barcodes affixed to a device identify its type, not instance. For FDA mandated Unique Device Identifier (UDI), use the Device.udi element

udi

FDA mandated Unique device identifier

type

Device type, SNOMED encoded.



Retrieving Patient's device Implant Event

The patient's PID used to retrieve the patient, a suffix ‘I’, an incrementing number, and an additional ‘-A’ suffix is passed as part of the URL to retrieve all device implantation events. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/ActivityDefinition/patientidIincrement-A



GET https://your.FHIRserver.com/ActivityDefinition?date=gedaterangelowerlimit&date=ledaterangeupperlimit&topic=Patient/patientidA



Name

Description

id

The logical ID of the event. This is based on the patient ID.

date

Date that the device was implanted.

topic

Patient that the device was implanted in.



The patient's implantable device impantation activity is returned. The following table describes the information returned

Name

Description

id

Device record unique identifier.

status

Indicates whether the activity has been performed.

date

Date the device was implanted.

description

Text description of the implant procedure.

code

Implantation procedure code. SNOMED or CPT.

topic

Patient that the device was implanted in.

relatedArtifact

Device that was implanted.



Retrieving Patient's Procedure

The patient's PID used to retrieve the patient, a suffix ‘F’, and an incrementing number is passed as part of the URL to retrieve all procedures. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/Procedure/patientidFincrement



GET https://your.FHIRserver.com/Procedure?date=gedaterangelowerlimit&date=ledaterangeupperlimit&patient=Patient/patientidA



Name

Description

id

The logical ID of the procedure. This is based on the patient ID.

date

The date the procedure was performed.

patient

Patient that the procedure was performed for.


The patient's procedure is returned. The following table describes the information returned



Name

Description

id

Procedure unique Identifier.

status

Status of the procedure, (In-Progress, Completed).

code

Identification code for the procedure that indicates the procedure performed from SNOMED-CT, or CPT.

performedDateTime

The procedure performed date and time

subject

Patient that the procedure was performed for.



Querying and retrieving Patient's Allergy

The patient's PID used to retrieve the patient, a suffix ‘D’, and an incrementing number is passed as part of the URL to retrieve all allergies. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/AllergyIntolerance/patientidDincrement



GET https://your.FHIRserver.com/AllergyIntolerance/patientidDincrement?date=gedaterangelowerlimit&date=ledaterangeupperlimit&patient=Patient/patientidA





Name

Description

id

The logical ID of the allergy. This is based on the patient ID.

date

The date the Allergy was recorded.

patient

Patient that has the allergy.



The patient's allergy is returned. The following table describes the information returned

Name

Description

id

Allergy unique Identifier.

assertedDate

Date when the Allergy was recorded

clinicalStatus

Status of the identified allergy or intolerance. The status code will be taken from the AllergyIntolerance  status value set and the option include 'Active', 'Inactive'

Code

RxNorm Code

criticality

Severity of the reaction or the event. Option include 'Mild' / 'Moderate' or 'Severe'

patient

Patient that has the allergy.



Retrieving Patient's Medication

The patient's PID used to retrieve the patient, a suffix ‘C’, and an incrementing number is passed as part of the URL to retrieve all medications. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/MedicationStatement/patientidCincrement



GET https://your.FHIRserver.com/MedicationStatement/patientidCincrement?effective=gedaterangelowerlimit&effective=ledaterangeupperlimit&subject=Patient/patientidA



Name

Description

id

The logical ID of the medication record. This is based on the patient ID.

effective

The date the patient started on the medication.

subject

The patient the medication is for.



The patient's medication statement is returned. The following table describes the information returned



Name

Description

id

Medication unique Identifier.

status

Medication Status. Option include 'Active', 'Completed'. For more information on this value set, see medication-order-status.

medicationCodeableConcept

Medication being administered or to be taken. For more details, Refer to RxNorm code set.

effectiveDateTime

The date the patient started on the medication. YYY-MM-DD format

subject

The patient the medication is for.



Retrieving Patient's Lab Tests

The patient's PID used to retrieve the patient, a suffix ‘K’, and an incrementing number is passed as part of the URL to retrieve all laboratory test orders. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/ProcedureRequest/patientidKincrement



GET https://your.FHIRserver.com/ProcedureRequest?occurrence=gedaterangelowerlimit&occurrence=ledaterangeupperlimit&patient=Patient/patientidA



Name

Description

id

The logical ID of the test. This is based on the patient ID.

occurrence

Date the laboratory test was ordered.

patient

Patient the laboratory test was ordered for.



The patient's Test Script is returned. The following table describes the information returned



Name

Description

id

Lab test unique Identifier.

code

Identifier for the type of test ordered. LOINC.

occurrenceDateTime

Date the laboratory test was ordered.

requisition

External name for the order - is the Lab vendor order number.

subject

Patient the laboratory test was ordered for.



Retrieving Patient's Lab Results

The patient's PID used to retrieve the patient, a suffix ‘H’, and an incrementing number is passed as part of the URL to retrieve all laboratory test results. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/DiagnosticReport/patientidHincrement



GET https://your.FHIRserver.com/DiagnosticReport?date=gedaterangelowerlimit&date=ledaterangeupperlimit&patient=Patient/patientidA



Name

Description

id

The logical ID of the result. This is based on the patient ID.

date

Date of the laboratory test result

patient

Patient the laboratory test was for.



The patient's Lab Results is returned. The following table describes the information returned





Name

Description

id

Lab result unique Identifier.

identifier

Unique Identifier for the observation instance. External ID - is for the Lab vendor to send the results such that this ID matches to the order.

status

Status of the result value or codes providing the status of the observation. The option includes, 'Final' , Preliminary' , 'Cancelled' etc.

code

Code refers to the test that is performed. This is the element bound to the LOINC coded elements.

effectiveDateTime

For lab test, this is the date and tie this observation was made available to the provider

contained-Observation

An actual result of the laboratory test.

-code

Code refers to the test that was ordered. This element is bound to the LOINC coded elements.

-valueQuantity

Numeric results of the test.

-valueCodableConcept

Codeable result of the test, i.e. positive, negative, etc.

subject

Patient the laboratory test was for.



Retrieving Patient's Vitals

The patient's PID used to retrieve the patient, a suffix ‘E’, an incrementing number, a hyphen, and sub id’s that increment from 1 through E in base 16 notation, is passed as part of the URL to retrieve all patient vital signs. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/Observation/patientidEincrement-sub-id



GET https://your.FHIRserver.com/Observation?date=gedaterangelowerlimit&date=ledaterangeupperlimit&patient=Patient/patientidA



Name

Description

id

The logical ID of the vital sign. This is based on the patient ID.

date

Date of the vital sign check.

patient

Patient the vital recording was taken from.



The patient's Vital signs are returned. The following table describes the information returned



Name

Description

id

Vital sign unique Identifier.

status

Status of the result value.

code

Vital Signs result type are coded responses to LOINC coded tests.

effectiveDateTime

Clinically relevant time/time-period for captured vitals signs.

valueQuantity

Vitals Signs value records. The codes shall be taken from the UCUM units as defined in http://unitsofmeasure.org

valueQuantity-value

The value of the measured amount. The value includes an implicit precision in the presentation value

valueQuantity-unit

A human-readable form of the units.

subject

Patient the vital recording was taken from.



Retrieving Patient's Care Team Members

The patient's PID used to retrieve the patient, a suffix ‘N’, and an incrementing number is passed as part of the URL to retrieve references to all care team members. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/CareTeam/patientidNincrement



GET https://your.FHIRserver.com/CareTeam?date=gedaterangelowerlimit&date=ledaterangeupperlimit&subject=Patient/patientidA



GET https://your.FHIRserver.com/Practitioner/referenced-practitioner-id



Name

Description

id

The logical ID of the care team member. This is based on the patient ID.

date

Dates that the provider was part of the patients care team.

subject

Patient the provider is a care team member of.



The care team list is returned. The following table describes the information returned.



Name

Description

id

Practitioner unique Identifier.

status

Whether the provider is currently a current care team member.

subject

Patient the provider is a care team member of.

period

Dates the provider was a member of the patients care team.

participant

Contains a reference to the detailed information about this provider.



When getting the referenced information, the patient's Practitioners are returned. The following table describes the information returned.



Name

Description

id

Practitioner unique Identifier.

identifier

NPI number of the provider.

name

The care providers name.

telecom

Practitioner contact communication detail. This indicates the value in any kind of telecom details field for the patient.

address

Portion of the provider’s address.



Retrieving Patient's Health Concerns

The patient's PID used to retrieve the patient, a suffix ‘M’, and an incrementing number is passed as part of the URL to retrieve all health concerns. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/Condition/patientidMincrement



GET https://your.FHIRserver.com/Condition?category=additional-concern&onset-date=gedaterangelowerlimit&onset-date=ledaterangeupperlimit&subject=Patient/patientidA



Name

Description

id

The logical ID of the health concern. This is based on the patient ID.

onset-date

The date the concern started.

subject

The patient that has the concern.

category

Always “additional-concern” for patient health concerns.





The patient's Health Concerns are returned. The following table describes the information returned.



Name

Description

id

Health Concern unique Identifier.

clinicalStatus

Status of the health concern.

code

The SNOMED or ICD10 code for the concern.

onsetString

Date the concern started.

onsetDateTime

Date the concern started.

subject

The patient that has the concern.



Retrieving Patient's Assessment and Plans

The patient's PID used to retrieve the patient, a suffix ‘L’, and an incrementing number is passed as part of the URL to retrieve all Assessment and Plans. You can also search for ones associated with the patient or a date range.



GET https://your.FHIRserver.com/CarePlan/patientidLincrement



GET https://your.FHIRserver.com/CarePlan?date=gedaterangelowerlimit&date=ledaterangeupperlimit&patient=Patient/patientidA



Name

Description

id

The logical ID of the Care Plan. This is based on the patient ID.

date

Date the Plan was made.

patient

Patient the Plan is for.



The patient's Care Plans are returned. The following table describes the information returned



Name

Description

id

Assessment and Plan unique Identifier.

status

Status of the assessment and plan.

period

Date period the plan covers

activity

One activity in the plan

activity.extension

Date this activity was planned

activity.category

What type of activity involved. Clinical Instruction, Future Appointment, etc.

activity.code

Specific SNOMED, CPT, RxNorm, or LOINC for the planned activity.

activity.ScheduledDateTime

When the activity is scheduled for.

activity.dailyAmount

Daily quantity.

activity.quantity

Total quantity.

activity.description

Text description of activity.

activity.goal

Goal this activity is in support of.

activity.performer

Who is scheduled to administer activity.

subject

Patient the Plan is for.



Retrieving a patient's CCDA documents

Patient visits and CDA records are stored as Lists. The patient's PID and suffix ‘Q’ is used to retrieve a List of all of the patients visits and CDA records. You can also search for ones associated with the patient or a date range by searching for lists for that patient and date. The lists include absolute path links on the server to the CCDA documents. See the qualifying searches by date section for information about patient Lists.



GET https://your.FHIRserver.com/List/patientidQ



GET https://your.FHIRserver.com/List?identifier=PSMD&date=gedaterangelowerlimit&date=ledaterangeupperlimit&subject=Patient/patientidA



GET https://your.FHIRserver.com/listed-reference





Name

Description

id

Binary file unique Identifier.

identifier

Hard coded as “PSMD”

date

Date of the visit the file was created for.

subject

Patient the document is for.



The patient's FHIR Document (CCDA) is returned in the content as a base 64 formatted binary file.





Copyright 2018 Data Tec, Inc.  All rights reserved.
HL7, CDA, CCD and FHIR are the registered trademarks of respective companies/organizations.
